Garador Chevron Cedar (7 Colour Options) Up and Over garage door Timber Garador

The Chevron Cedar Timber up and over garage doors are made from the highest quality timber and are built around a steel sub frame, which will provide stability and strength.

All of the timber garage doors are supplied with a neutralising base stain and are ready for on-site finishing.

Factory Fitted Steel Fixing Frame

We highly recommend the Garador steel fixing frame as it offers the tightest tolerance around the edge of the door panel, creating a faster and neater fit compared to a standard timber subframe.

Canopy mechanism with steel frame

Retractable mechanism with steel frame

Choose Handle Option
Choose either a black nylon handle or a high quality diecast metal handle in white, brass or chrome effect.

Extra Security Locking
For manually operated doors we offer the option to upgrade to a 4 point locking rod system for improved security and resistance to forced entry. Combined with a steel sub frame the Garador locking rod system utilises the steel closing lip along with steel plates to prevent easy access to the internal locking catches for the door.

The improved security of a locking latch in each corner protects against forced entry.

Suitable for retractable gear options the electric operated ‘De Latch Security Locking’ system works with the existing manual locking mechanism, and the remote control operator, by connecting with a mechanical latching system to provide 3 point locking security.

The ‘De Latch Security Locking’ system is not suitable for canopy doors.

Emergency External Release
Required for garages without alternative means of access to the garage. This system attaches a cable internally, within the garage, and offers a way to externally disconnect the remote control operator towing arm, perfect in the event of a power failure.

Remote Control Electric Operator
Complete with two hand transmitters the Garamatic 9 electric operator is reliable, secure and offers excellent value for money.  The operator is maintenance free and creates a super smooth and quiet door. Other features include a manual override option, for the event of power failure, an integral LED light with 10 LEDs to combine for low power consumption and it complies with the latest European safety standards. Short K boom is included with this motor, it will be suitable for doors up to 2500mm high.

Please note that the Retractable doors do not have a back brace.

Factory Finished Door Colour Options:
Light Oak
Mahogany
Antique Oak
Walnut
Chestnut
Ebony

Timber doors are supplied untreated and require immediate on-site finishing unless a fully finished option has been chosen.

Garador cannot guarantee to be able to produce matching timber garage doors, as timber is a natural material.

The chassis colour will be Brown RAL 8028.

All timber doors are built around a steel subframe providing structural stability and inherent strength. With initial and regular staining, the door will keep its stunning appearance and last a lifetime.

Diecast Handle Options:
Black handle and base plate supplied as standard
Brass effect
Chrome effect
White

Doors can alternatively be supplied undrilled and without handle and locking mechanism for use with an electric operator.

Garamatic 9 (Peak Force 750N)
> Fast opening with a maximum speed of 14cm per second
> Automatic locking preventing forced entry
> Integral light
> Soft start and soft stop
> Equipped with status query technology to indicate whether your garage door is open or closed
> Simple to operate

De-Latch Security Locking Kit
When an electric operator is fitted the garage door only locks on the operator – the door is not locked on the locking catches fitted to the door. A delatch kit will engage the locking catches on the garage door as well providing a further level of security

Optional Retractable Plus Gear - available on 1931mm, 1981mm and 2136mm high doors and up to 2284mm wide.

Retractable Plus Gear is an optional extra for garages that have narrow openings, they have specially designed lifting arms and bottom spring brackets to allow for maximum use of the clear passage.

Retractable Plus Gear is not available for doors over 7'6" wide

Installation details provided with every door.

Warranty

Timber doors: 2 years. Warranty is granted on the door panels alone under the terms and conditions specified herein. The door mechanism and steel frame (if applicable) is covered by the 10 year warranty period. Replacement Parts: 6 months.

GRP Doors: 2-year Warranty on the door panels. 10-year Warranty on the door mechanism and steel frame.

Steel Doors: 10-year Warranty. Replacement Parts: 6 months.

The Warranty does not cover damage caused through:

> Normal wear and tear

> Improper installation

> Negligent care and maintenance

> Improper initial and subsequent operation

> Negligent or wanton destruction

> External influences such as fire, water, salts, alkaline solutions, acids, abnormal environmental influences

> Mechanical damage through improper transport and fitting

> Priming and other surface protection treatments

> Repair by non-qualified persons

> Using non-Garador parts without the approval of the Manufacturer

> Remove of the product number or making it unidentifiable

Garador Up and Over Service and Support: Information on operation, maintenance and cleaning of your garage door.

Canopy Gear


Retractable Gear
